Equipment Type
|
Engines |
|
Air Cleaner Type
|
Dual element |
|
Bore and Stroke (in#)
|
3.2 x 2.5 |
|
Charging Amps
|
10 |
|
Choke System
|
Manual |
|
Compression Ratio
|
8.2:1 |
|
Cooling System
|
Air cooled |
|
Crankshaft Type
|
Q-type |
|
Cylinder Bore
|
Cast iron |
|
Cylinders
|
1 |
|
Engine Displacement
|
389cc |
|
Engine Type
|
GX Series OHV Commercial-Duty |
|
Fuel Filter
|
Fuel tank filler neck strainer |
|
Fuel Tank
|
Standard (White) |
|
Fuel Tank Capacity (Qt#)
|
6.4 |
|
Fuel Type
|
Gasoline |
|
Item No_
|
GX340UT2QNE2 |
|
Low Oil Alert
|
Yes |
|
Low Oil Shutdown
|
Yes |
|
Lubrication System
|
Forced splash |
|
Max# RPM
|
3,600 |
|
Muffler Included
|
Standard, exhaust pipe protector, deflector |
|
Net Power Output
|
10.7 (8.0 kW) at 3,600 RPM |
|
Net Torque (lbs#/Ft)
|
19.5 (26.4 Nm) at 2,500 RPM |
|
Oil Capacity (Qt#)
|
1.16 |
|
PTO Height
|
5.25 |
|
Shaft Diameter (in#)
|
1 |
|
Shaft End Tapped
|
3/8 24 |
|
Shaft Keyway
|
0.25 |
|
Shaft Length (in#)
|
3.484375 |
|
Shaft Output
|
Horizontal |
|
Shaft Rotation (from PTO shaft side)
|
Counterclockwise |
|
Start Type
|
Electric w/recoil backup |
|
Throttle Control
|
Manual |
